UL 21811 2C × 18AWG + W 80℃ 30V TPE Jacket UV resistance tinned copper stranded Cable
Product Description
Application: Internal wring or external interconnection of electronic equipment.
Application standard: Outdoor
Product character:
Flame rated : FT1
Tensile strength:≥8.3 MPa Elongation:≥200%
Aged condition:121℃×168H
Percent of original tensile strength: ≥75%
Percent of original elongation: ≥75%
UL758 -E258652-20060111-CertificateofCompliance-1....
| Construction |
| Conductor | Tinned copper solid |
| Cross section | 18AWG |
| Construction | 16/0.254mm |
| Strand Dia. | 1.17mm |
| Insulation | PE |
| Nom.Thickness | 0.20mm |
| Min.Thickness | 0.18mm |
| Insulation Dia. | 1.90±0.10mm |
| Insulation colour | 1.red 2.white |
| Drain | / |
| Material | Non-woven |
| Assembly | 2C×18AWG+W |
| Jacket | TPE(UV resistance) |
| Nom.Thickness | 0.41mm |
| Min.Thickness | 0.33mm |
| Outer Dia. | 5.30±0.20mm |
| Colour | per request |
Insulation:TPE
Conductor : Tinned copper
Construction
Insulation:1.red 2.white
Jacket : per request
Jacket: TPE(UV resistance)
Application
These cables are appropriate for flexible use with medium mechanical stresses, and free movement without tensile stress or forced movements in dry, moist and wet rooms but not open air. Suitable to be used as measuring and control cables in tool machines,
Standards
International: NOUL
RoHS,REACH Compliant,
Technical data
Rated voltage:30V
Rated Temperature: 80℃
Flame: FT1
Voltage withstand test:AC 0.5kV/1min
Properties
Effectively resist electromaganetic interference
Excellent insulation performance
Extensively oil resistant
Flexible
| Electric Performance |
| Rated Temperature | 80℃ |
| Voltage rating | 30V |
| Max.conductor DC resistance(20℃) | 23.2Ω/km |
| Dielectric Strength AC | 0.5kV/1min |
