HO7RN standard Bared copper stranded 2C × 1.5 mm2 450V/750V CPE jacket 90 deg C Cable
| ITEM | 2C×1.5mm2(30/0.254B) |
| CONDUCTOR | Material | Bared copper stranded |
| Size | 30/0.254mm |
| O.D.(Ref) | 3.40±0.15mm |
| INSULATION | Material | EPR |
| Min.average thickness | 0.8mm |
| Min.thickness at any point | 0.8mm |
| O.D. | 3.40±0.15mm |
| CABLING | Filler | Optional |
| Material | |
| Assembly | 2C×1.5mm2(30/0.254B) |
| BRAID | Material | / |
| Size | / |
| JACKET | Material | CPE |
| Nom.average thickness | 1.80mm |
| O.D. | 10.10±0.30mm |
Conductor Bared copper stranded
Cross section 2C×1.5mm2(30/0.254B)
Construction 37/0.26B
Elongation ≥100%
Strand Dia.(Ref.) 1.85mm
Aged condition 136±1℃×168h
Insulation EPR
Nom.Thickness 0.8 mm
Min.Thickness 1.18mm
Insulation Dia. 3.40±0.15mm
nsulation: :brown,blue
Jacket CPR
Reference standard:VCT standard
Nom.Thickness 1.5mm
Outer Dia. 10.1±0.30mm
Colour per request
UL758-E258652-20060111A-CertificateofCompliance(2)...
绝缘原始机械性能,抗张强度≥5.0MPa,断裂伸长率≥200%
Initialmechanicalpropertyofinsulation,tensilestrength≥5.0MPa,elongationatbreak≥200%
100±2℃,168h老化后,抗张变化率≤±25%,伸长变化率≤±25%
Afteragingat100±2℃,168h,Variationoforiginaltensilestrength≤±25%,Variationoforiginalelongation≤±25%
试验方法符合EN50525-2-21的规定.
TestmethodisinaccordancewithEN50525-2-21.
