Frpe Insulated Industrial Flexible Cable Losh UL2464 Cable 28AWG

Brand Name : Hwatek

Model Number : UL2464

Certification : ISO9001, UL, CCC, RoHS

Place of Origin : China

MOQ : 305m,610m or as Request

Price : $0.5-1

Payment Terms : T/T

Supply Ability : 30KM/Day

Delivery Time : 5-8 Weeks

Packaging Details : Rolled in Reels, Packed in Pallets.

Material Shape : Round Wire

Color : Optional

Transport Package : Rolled in Reels, Packed in Pallets.

Typ : Insulated

HS Code : 8544492100

Contact Now

Losh UL2464 Cable 28AWG Frpe Insulated Tinned Copper Stranded

Product Description

ITEM 34C×28AWG(7/0.127T)
CONDUCTOR Material Tinned copper stranded
Size 7/0.127±0.008mm
O.D.(Ref) 0.38mm
INSULATION Material FRPE
Min.average thickness 0.25mm
Min.thickness at any point 0.20mm
O.D. 0.90±0.05mm
CABLING Filler PP rope
Material Al-mylar(face out) overing : 25% min.
BRAID Material Tinned copper
Size 24/9/0.10mm , 80% min.
JACKET Material NH
Min.average thickness 0.88mm
Min.thickness at any point 0.70mm
O.D. 8.60±0.25mm
ELECTRICAL CHARACTERISTICS PHYSICAL PROPERTIES
Rated voltage:300V Insulation Jacket
Rated temperature:-25~90ºC Tensile strength: ≥8.27MPa ≥8.27MPa
Max. DC conductor resistance(20ºC):223.75Ω/km Elongation: ≥100% ≥100%
Voltage withstand test: Aged condition: 100±1ºC×48h 100±1ºC×48h
Core-Core : AC 1.5kV/1min Percent of original: ≥75% ≥75%
Core-Shield : AC 1.5kV/1min Percent of original: ≥75% ≥75%
Min.bending radius: Flexing 15×OD Cold Bend(-40±1ºCX4hrs) No Crack
Flxed 7.5×OD Heat Shock(121±1ºCX1hrs) No Crack
Flame test : FT2 , IEC 60332-1
Halogen free : Cl<900ppm,Br<900ppm
F+Cl+Br+I<1500ppm

Company Profiles
Founded in 2004 with 9 million USD capital investment, our HQ factory in Kunshan covers 14980 square meters.
In 2020 we established our Nantong facility with 100 million RMB capital investment which covers 34000 square meters.
With ISO9001, ISO14001, IATF16949, ISO13485 system certificates, all of our products have passed CCC, UL, CUL, CE, CSA, ETL safety certificates. We are working with global customers in various fields through our well-established sales system based on the management principal HONESTY, INNOVATION and ENVIRONMENTAL PROTECTION.
Frpe Insulated Industrial Flexible Cable Losh UL2464 Cable 28AWGFrpe Insulated Industrial Flexible Cable Losh UL2464 Cable 28AWG
Certificates
Frpe Insulated Industrial Flexible Cable Losh UL2464 Cable 28AWG
Production Progress
Frpe Insulated Industrial Flexible Cable Losh UL2464 Cable 28AWGShipping
Frpe Insulated Industrial Flexible Cable Losh UL2464 Cable 28AWGFAQ
1.Q:What can you supply?
A: We do produce consumer electronics wires, hock up wires, industrial cables, robot cables, ev charging cables, new/green energy cables.
2.Q: What are the certificates do you get?
A: We have UL, CE, 3C, Dekra, CQC, TUV, Rohs, Reach, ETL certificates.
3.Q:Can we get samples before ordering?
A:Yes, we are willing to arrange samples for you.
4.Q: What's your lead time?
A: Normally we can finish you orders in 2-3 weeks, and 5-6 weeks in peak season.
5.Q. How can you guarantee the product quality?
A: Always a pre-production sample before mass production and final Inspection before shipment.
